FLOOR / CEILING PANELS

HOW DID IT BEEN DONE?

PS300_Laepaneel-Temp0066
PS300_Laepaneel-Temp0066

press to zoom
PS300_Laepaneel-Temp0066
PS300_Laepaneel-Temp0066

press to zoom
1/1

Classic floor panel   module of wood-metal beams.

Technical specifications:



Payload 1.5 kN / m2 and 2.0 kN / m2

The thicknesses of the module can be as follows: 278 mm, 328 mm, 398 mm. Standard width 1200 mm,  The maximum length depends on the height of the module

Top covered with OSB3 board with a thickness of 18 mm, bottom with OSB3 board with a thickness of 10 mm

FLOOR HEATING AND SOUND INSULATION

3D_Seinad-Temp0000
3D_Seinad-Temp0000

press to zoom
3D_Seinad-Temp0000
3D_Seinad-Temp0000

press to zoom
1/1

Wood floor with concrete floor properties

Technical specifications:

A layer of concrete with a thickness of 50 mm adds 137 kg / m2 to the beams. Therefore, the installation of beams is usually one third denser than without concrete. OSB3 board thickness is not less than 18 mm.  Significantly  improves the soundproofing of the floor.

ROOF CEILING

PS300_LaepaneelRoovitusega-Temp0013
PS300_LaepaneelRoovitusega-Temp0013

press to zoom
PS300_LaepaneelRoovitusega-Temp0019
PS300_LaepaneelRoovitusega-Temp0019

press to zoom
PS300_LaepaneelRoovitusega-Temp0021
PS300_LaepaneelRoovitusega-Temp0021

press to zoom
PS300_LaepaneelRoovitusega-Temp0013
PS300_LaepaneelRoovitusega-Temp0013

press to zoom
1/3

Using roof panels saves time and money

Thickness of pnees up to 400 mm, width up to 1.8 m.

We use stone wool or PUR foam for insulation.

Roof panel  with a thickness of 350 mm and insulated with stone wool  U-number  0.9 W / m2 * K

When insulated with PUR foam, this figure is even better. The slope of the roof can be according to the project
